The Aeromapper 300 is probably the most complete UAV for survey & mappping applications at the most competitive price on the market. See for yourself. A powerful UAV yet very easy & friendly to use, with 1.5 hour endurance, with multisensor capabilities, easy parachute landing, hand launch, 20 km datalink range & +50 km control link, automatic terrain following, and of course fully automatic flight. The Aeromapper 300 is ideal for those very large areas that need to be surveyed or when you need to put two sensors "up there" at the same time, cutting on acquisition times.

The sensor lenses are protected during landing via a ventral sliding door that closes automatically when the mission is finished.

Cameras are installed in panoramic orientation for most optimal area coverage with maximum side overlap.

The Aeromapper 300 also complies with all the design standards for Unmanned Aerial Vehicles for Transport Canada.

We can guarantee is the toughest, strongest and most durable UAV you will ever see. It is entirely made of carbon fiber, with tough kevlar reinforcements in key areas. It is a working horse that can take a beating and still give you years of use.

The Aeromapper 300 is a proven and mature UAV, tested over the course of countless flight hours and in many conditions. No catapult launcher is required. No training is required.

SPECIFICATIONS:

Wing span: 3.0 m
Payload capacity: 650 grs, with 90mins endurance.
Takeoff: handlaunch. Catapult launcher available upon request.
Take-off Weight: 5350 gr.
Cruise Speed: 60 Km/h.
Maximum speed: +90 Km/h - Great stability and minimal roll & pitch oscillations in gusty conditions thanks to its low dihedral, small lateral profile and V tail rudder control = no gimbal required for cameras & sensors.
Parachute recovery system: ultra compact parachute with Kevlar lines. Very easy to pack in 2 minutes. Instructions provided in User Manual
Endurance: 90 mins
Take-off: fully automatic.
Landing: aircraft repeat passes over desired landing area at 40m until parachute is deployed via a single switch. Belly landing possible with pilot assistance in autostabilization mode. Automatic parachute release on waypoint also available upon request.
Autopilot: Pixhawk by 3DRobotics
Range: +20 kms data link, +50kms control.
Max. altitude: 4500 masl.
Failsafe: Automatically returns to home & loiter upon loss of RC link.
Flight modes: Manual, Stabilize, Return to Home, FBW, Auto.
Wind Tolerance: up to 40 km/h. 25km/h for parachuting down.
Telemetry: battery status, alt, ground speed, compass, attitude,distance travelled, time on air (speech enabled), and more. 915 or 868 Mhz.
Moving map display: drone position and heading, commands on map, fly to point on map, altitude changes, remote spot camera trigger, mission route, and more.
Low battery warning: visual and audible alarm warnings. Theresolds are user definable.
Mission Planning: altitude, side and lenght-wise overlaps, orientation of the lines, start & end waypoints, flying speed and overshoots are user definable. Drone automatically calulates fligth time, distance between images and triggers camera automatically. Distance between lines is calculated automatically according to desired side overlap.
Weather: all weather performance. The Aeromappers can fly in light rain. All it's electronics are enclosed.
Payloads: 24Mp standard. 36Mp camera available. Many more sensors are available here.

AREA COVERAGE CHART

GSD (ground resolution)	Altitude AGL (meters)	Area coverage per flight
1.6 cm/pixel	85 m	4.3 km²
2.4 cm/pixel	125 m	6.6 km²
4.8 cm/pixel	250 m	13 km²
7.8 cm/pixel	400 m	21.4 km²
11.7 cm/pixel	600 m	31 km²
