GENERAL INFORMATION |
Weight |
13~15kg |
Dimension |
305X120X65cm |
Wingspan |
3.0 m (9.84ft) |
Material |
Carbon fiber & honey comb structure, VARTM processing technology |
Battery |
Hi-Capacity Li-Po battery 11.1V 28000mAH(Power Battery) 8000 mAH(Avionics Battery) |
Propulsion |
1500W Brushless Motor, Pusher configuration |
Speed |
64-129km/hr(35-70knot) |
Altitude |
4000m (13123ft)(AMSL) |
Endurance |
2.5-3hr |
CAMERA CAPABILITY |
Camera Model |
Nikon D810, Lens 35mm Digital Camera or equivalent |
Resolution |
36.3 Mega Pixels |
Aperture |
F1.8 |
TAKE-OFF/LANDING |
Take-off |
Auto-Launch Catapult (optional) |
Landing |
Parachute |
WEATHER CONDITION |
Wind Force |
Beaufort wind scale 6 and under |
Rain Force |
Drizzle(Light Rain) |
FREQUENCY/CONTROL/POST PROCESSING |
Radio Frequency |
2.4G or customizable |
19200bps, Half-duplex, 10 channels(Channel hopping) |
Radio Tx Frequency |
Pannel Antenna : 30km |
Photo Area |
30sq-km (AGL 500m) |
Front Overlap |
70% |
Side Overlap |
60% |
Ground Equipments |
Radio signal control (Controlling Box + Pannel Antenna) |
Backup Battery |
Notebook Computer |
Ground Control Station Software |
Post Processing Software |
Pix4D/PhotoScan(optional) |
Application |
Application |
Aerial Mapping |
Disaster Emergency |
Works Supervision |
Agricultural Survey |
Survey of Vegetation |
|
|
